094-6636-0000 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

094-6636-0000

Part No 094-6636-0000
Manufacturer TE Connectivity
Catalog D-Sub, D-Shaped Connectors - Assemblies
Description CONN MICRO-D RCPT 37POS SLDR CUP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Connector Style D-Type, Micro-D
Connector Type Receptacle, Female Sockets
Number of Positions 37
Number of Rows 2
Mounting Type Free Hanging (In-Line)
Contact Type Signal
Flange Feature Housing/Shell (Unthreaded)
Termination Solder Cup
Shell Material, Finish Metal, Yellow Chromate Plated Cadmium
Contact Finish Gold
Contact Finish Thickness 50.0µin (1.27µm)
Features Reverse Layout
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1622801-094-6636-0000
Ultra Librarian 3D Model Ultra Librarian 094-6636-0000 CAD Model

Description

N
