Same model may have multiple batches, images only for reference.

PH50S48-12

Name: PH50S48-12
Brand: TDK-Lambda Americas Inc.
SKU: 930341
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PH50S48-12
Manufacturer	TDK-Lambda Americas Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 12V 50W / Isolated Module DC DC Converter 1 Output 12V 4.2A 36V - 76V Input
Datasheet	PH50S48-12 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	TDK-Lambda Americas Inc.
Series	PH-S (50W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	36V
Voltage - Input (Max)	76V
Voltage - Output 1	12V
Current - Output (Max)	4.2A
Power (Watts)	50 W
Voltage - Isolation	3 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, OVP
Temperature Range - Operating	-20°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Module
Control Features	Enable, Active Low
Standard Package	1 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	930341-PH50S48-12
Ultra Librarian 3D Model	Ultra Librarian PH50S48-12 CAD Model

Alternative Products

Description

The PH50S48-12 is an isolated module DC DC converter from TDK-Lambda Americas Inc.

Series: PH-S (50W) series
Category: Power supplies - board mount - DC DC converters
Features: Remote on/off, overcurrent protection (OCP), overtemperature protection (OTP), and overvoltage protection (OVP)
Package: Bulk package
Power Output: 50W
Output: Single output with a maximum current of 4.2A
Input Voltage Range: 36V to 76V
Output Voltage: 12V
Voltage Isolation: 3kV
Mounting: Through-hole mounting type
Temperature Range: -20°C to 85°C
Product Status: Obsolete product
