Same model may have multiple batches, images only for reference.
PH150F48-24
Same model may have multiple batches, images only for reference.

PH150F48-24

Part No PH150F48-24
Manufacturer TDK-Lambda Americas Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 24V 150W / Isolated Module DC DC Converter 1 Output 24V 6.3A 36V - 76V Input
Datasheet
PH150F48-24 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr TDK-Lambda Americas Inc.
Series PH-F (150W)
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 36V
Voltage - Input (Max) 76V
Voltage - Output 1 24V
Current - Output (Max) 6.3A
Power (Watts) 150 W
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP, OVP
Temperature Range - Operating -20°C ~ 85°C
Mounting Type Through Hole
Package / Case Module
Size / Dimension 3.39" L x 3.27" W x 0.50" H (86.0mm x 83.0mm x 12.7mm)
Control Features Enable, Active Low
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 930332-PH150F48-24
Ultra Librarian 3D Model Ultra Librarian PH150F48-24 CAD Model

Description

The 930332-PH150F48-24 is a high-power isolated module power supply designed for board mount applications in the field of power electronics.

  • Series: PH-F series
  • Power Output: 150W
  • Size: 3.39" L x 3.27" W x 0.50" H (86.0mm x 83.0mm x 12.7mm)
  • Features: Remote On/Off, overcurrent protection (OCP), and overvoltage protection (OVP)
  • Input Voltage Range: 36V to 76V
  • Output Voltage: Single output voltage of 24V
  • Maximum Output Current: 6.3A
  • Manufacturer: TDK-Lambda Americas Inc.
  • Package: Packaged in bulk
  • Product Status: Obsolete product range
  • Voltage Isolation: 3kV
  • Mounting: Through-hole mountable
  • Temperature Range: -20°C to 85°C
  • HTSUS code: 8504.40.9580
