VLS3012T-220MR49 Real Image
Same model may have multiple batches, images only for reference.

VLS3012T-220MR49

Part No VLS3012T-220MR49
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 22UH 490MA 756 MOHM
Datasheet
VLS3012T-220MR49 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Not For New Designs
Type Wirewound
Inductance 22μH
Tolerance ±20%
Current Rating 490mA
Current - Saturation 490mA
DC Resistance (DCR) 756 mOhm Max
Temperature Range - Operating -40°C to 105°C
Frequency - Test 1MHz
Mounting SMD (SMT)
Height - Seated (Max) 0.047" (1.20mm)
Win Source Part Number 036396-VLS3012T-220MR49
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VLS3012T-220MR49 CAD Model

Description

TDK Corporation's VLS3012T-220MR49 is a wirewound inductor that is designed to provide high inductance with low DC resistance.

  • Current Rating: 490 mA
  • Inductance: 22 µH
  • Mounting: SMD (SMT) mountable
  • Tolerance: ±20%
  • Operating Temperature Range: -40°C to 105°C
