CGGBP.18.4.A.02

Part No CGGBP.18.4.A.02
Manufacturer Taoglas Limited
Catalog RF Antennas
Description RF ANT 1.56/1.575GHZ CER PATCH
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Navigation
Frequency Group UHF (1GHz ~ 2GHz)
Frequency (Center/Band) 1.56GHz, 1.575GHz, 1.602GHz
Frequency Range 1.548GHz ~ 1.615GHz
Antenna Type Ceramic Patch
Number of Bands 3
VSWR 2.8, 2.8, 1.8
Return Loss -10dB
Gain 3dBi, 2dBi, 4dBi
Termination Pin
Mounting Type Connector Mount
Height (Max) 0.157" (4.00mm)
Applications Beidou, GLONASS, GPS
Package Tray
Supply and Demand Status Normal
Win Source Part Number 1510846-CGGBP.18.4.A.02
Ultra Librarian 3D Model Ultra Librarian CGGBP.18.4.A.02 CAD Model
