Same model may have multiple batches, images only for reference.

SMCJ6.0

Name: SMCJ6.0
Brand: Taiwan Semiconductor
SKU: 668944
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SMCJ6.0
Manufacturer	Taiwan Semiconductor
Catalog	TVS - Diodes
Description	1500W, 7.4V, 10%, UNIDIRECTIONAL
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Taiwan Semiconductor
Series	SMCJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	6V
Voltage - Breakdown (Min)	6.67V
Voltage - Clamping (Max) @ Ipp	11.4V
Current - Peak Pulse (10/1000µs)	138A
Power - Peak Pulse	1500W (1.5kW)
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMC)
Base Product Number	SMCJ6.0
Standard Package	3,000 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	668944-SMCJ6.0
Ultra Librarian 3D Model	Ultra Librarian SMCJ6.0 CAD Model

Alternative Products

Description

The 668944-SMCJ6.0 is a Zener type transient voltage suppressor diode designed to protect electronic circuits from voltage surges and transients.

Voltage - Reverse Standoff (Typ): 6V
Voltage - Breakdown (Min): 6.67V
Voltage - Clamping (Max) @ Ipp: 11.4V
Power - Peak Pulse: 1500W
Channel Type: Unidirectional
Mounting Type: Surface Mount
Operating Temperature: -55°C to 150°C
Manufacturer: Taiwan Semiconductor
Series: SMCJ
Application: General Purpose
Packaging: Tape and Reel
Product Status: Active
