STM8S208R8T6 Microcontroller Overview

The STM8S208R8T6 is a high-performance microcontroller unit (MCU) from STMicroelectronics, designed to deliver the perfect balance between performance, power consumption, and cost-effectiveness. This device is part of the STM8S series, which are optimized for industrial and consumer applications requiring high levels of integration and robustness.

Key Features

• Core: STM8 core operating at up to 24 MHz frequency.
• Flash Memory: 64 Kbytes of Flash program memory with read-while-write support.
• RAM: 6 Kbytes of RAM provide ample space for data storage and manipulation.
• Data EEPROM: 2 Kbytes of true data EEPROM with up to 300,000 write/erase cycles ensure data retention and dynamic storage.
• Advanced Control Timer: A sophisticated timer for complex waveform generation and motor control applications.
• Communication Interfaces: Integrated UART, SPI, and I2C interfaces for versatile peripheral connections and data exchange.
• 10-bit ADC: An analog-to-digital converter with up to 16 channels for precise measurement and monitoring of analog signals.
• I/O Ports: Up to 68 I/O ports, with interrupt capability, provide extensive interfacing capabilities.
• Operating Voltage: A wide range of operating voltage from 3.0 V to 5.5 V to accommodate various power supply conditions.

Applications

The STM8S208R8T6 is suitable for a broad array of applications due to its robust feature set. These applications include:

• Automotive systems
• Industrial controls
• Home appliances
• Consumer electronics
• Complex system management

Design Support

STMicroelectronics provides comprehensive development support for the STM8S208R8T6 MCU, including software libraries, development boards, and a robust integrated development environment (IDE) to streamline the development process. This ensures that developers can maximize the capabilities of the STM8S208R8T6 and reduce time-to-market for their products.
