STM8S105K6T6C Microcontroller Overview

The STM8S105K6T6C is a high-performance microcontroller unit (MCU) from STMicroelectronics, designed for a broad range of applications. This MCU is part of the STM8S series, which is well-known for its robust architecture, enhanced peripherals, and low power consumption. The STM8S105K6T6C offers a cost-effective solution for embedded systems that require reliable operation and a rich set of features.

Key Features

• Core: The STM8S105K6T6C is built around an advanced STM8 core running at up to 16 MHz, delivering great performance and efficiency.
• Memory: It comes with 32 Kbytes of Flash program memory, 2 Kbytes of RAM and 1 Kbyte of EEPROM, which is ideal for storing firmware, application data, and user parameters that need to be preserved during power cycles.
• I/O Ports: This MCU provides up to 34 I/O ports with 5V tolerant capability, making it suitable for interfacing with a wide range of sensors and actuators.
• Timers: It includes versatile timers, including four 16-bit timers and one 8-bit timer, which can be used for tasks such as PWM generation, time-base generation, and pulse measurement.
• Communication Interfaces: The MCU supports multiple communication interfaces, including I2C, SPI, and UART, allowing for easy integration into communication networks.
• ADC: An integrated 10-bit analog-to-digital converter (ADC) with up to 5 multiplexed channels enables the MCU to process analog signals.
• Operating Voltage: The operating voltage ranges from 2.95 V to 5.5 V, providing flexibility in different power environments.
• Temperature Range: It operates within an industrial temperature range from -40°C to 85°C, ensuring reliable performance under extreme conditions.

Applications

The STM8S105K6T6C is a versatile MCU that can be used in a variety of applications, including industrial control systems, home appliances, automotive electronics, and consumer devices. Its robust feature set and ease of use make it an excellent choice for both simple and complex applications that require a balance between performance and cost.

Package and Quality

The STM8S105K6T6C is available in an LQFP 32-pin package, which is suitable for space-constrained applications. STMicroelectronics is committed to high-quality standards, and this product is no exception, ensuring reliable operation for the lifetime of your application.
