The LMV324IYPT is a high-performance, low-power quad operational amplifier designed and manufactured by STMicroelectronics, one of the leading names in semiconductor solutions. This operational amplifier is part of the LMV3xx series and is particularly suited for applications that require a balance between power efficiency and operational proficiency.

Key Features

• Low Voltage Operation: The device can operate at a supply voltage range from 2.7V to 5.5V, making it versatile for both single and dual-supply operations and well-suited for battery-powered devices.
• Low Power Consumption: With a quiescent current of just 220 µA per channel, the LMV324IYPT is optimized for power-sensitive applications.
• Rail-to-Rail Output: The rail-to-rail output capability allows for a wider dynamic range, which is especially beneficial in low-voltage applications.
• Input Common-Mode Voltage Range: Includes ground, which is ideal for direct sensing near ground.
• Gain Bandwidth Product: At 1MHz, it provides stable gain for moderate-speed applications.
• Extended Temperature Range: The device can operate over a wide temperature range from -40°C to +125°C, accommodating various environmental conditions.

Applications

The LMV324IYPT is well-suited for a variety of electronic applications, including but not limited to:

• Battery-powered devices
• Portable and compact electronics
• Signal conditioning
• Active filters
• Medical devices
• Automotive systems

Package and Quality

The LMV324IYPT comes in a compact TSSOP-14 (Thin Shrink Small Outline Package) that is space-efficient, making it ideal for designs where board space is at a premium. Additionally, STMicroelectronics ensures that the product meets rigorous quality standards, providing reliability and performance that engineers can depend on.
