The SM1628C is a LED controller driver with a keypad scan interface. This device is commonly used in various electronic applications to control and manage LED displays and to interface with keypad inputs.

Applications

• LED display devices
• Keypad input interfaces
• Consumer electronics (e.g., remote controls, home appliances)
• Instrumentation panels
• Microcontroller based projects requiring LED control and key input

Features

• LED drive capability: Supports multiple LEDs with individual control.
• Keypad scan interface: Integrated keypad scanning functionality simplifies keypad integration.
• Serial interface: Uses a serial communication protocol for command and data transfer.
• Adjustable brightness: Provides brightness control for LEDs.
• Low power consumption: Designed for efficient power usage.
• Display Mode: Supports multiple display modes for driving LEDs.

Benefits

• Simplified LED control: Eases the process of controlling multiple LEDs, reducing the complexity of the circuit design.
• Keypad integration: Streamlines keypad input by handling the scanning and debouncing internally.
• Reduced component count: Integrates LED control and keypad scanning into a single chip, reducing the number of external components required.
• Flexibility: Serial interface allows for easy communication with microcontrollers and other digital systems.
• Energy-efficient: Low power consumption makes it suitable for battery-powered applications.
• Cost-effective: Combines several functions into one chip, potentially reducing overall system costs.

Additional Details

The SM1628C typically operates with a supply voltage of 5V. The serial interface typically uses a three-wire interface (data, clock, and strobe). It supports common cathode LED displays. It finds usage in devices like set-top boxes, DVD players, and other consumer electronics requiring LED display and keypad input.
