SKY65805-696EK1 Real Image
Same model may have multiple batches, images only for reference.

SKY65805-696EK1

Part No SKY65805-696EK1
Manufacturer Skyworks Solutions Inc.
Catalog RF Evaluation and Development Kits, Boards
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>RF Evaluation and Development Kits, Boards
Mfr Skyworks Solutions Inc.
Package Box
Type Amplifier
Frequency 2.3GHz ~ 2.69GHz
For Use With/Related Products SKY65805-696LF
Supplied Contents Board(s)
Base Product Number SKY65805
Other Names 863-1998
Standard Package 1
MSL Level 1 (Unlimited)
HTSUS 8543.70.9860
Win Source Part Number 1283426-SKY65805-696EK1
Ultra Librarian 3D Model Ultra Librarian SKY65805-696EK1 CAD Model

Description

The Skyworks Solutions Inc. SKY65805-696EK1 is an amplifier development board designed for use with SKY65805-696LF.

  • Frequency Range: 2.3GHz to 2.69GHz
  • Package: box
  • Standard Package: 1
  • MSL level: 1 (unlimited)
  • HTSUS Code: 8543.70.9860
