Same model may have multiple batches, images only for reference.

SI8631EC-B-IS1R

Name: SI8631EC-B-IS1R
Brand: Skyworks Solutions Inc.
SKU: 814486
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI8631EC-B-IS1R
Manufacturer	Skyworks Solutions Inc.
Catalog	Digital Isolators
Description	DGTL ISO 3750VRMS 3CH GP 16SOIC
Datasheet	SI8631EC-B-IS1R Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators - Digital Isolators
Mfr	Skyworks Solutions Inc.
Package	Tape & Reel
Product Status	Active
Technology	Capacitive Coupling
Type	General Purpose
Isolated Power	No
Number of Channels	3
Inputs - Side 1/Side 2	2/1
Channel Type	Unidirectional
Voltage - Isolation	3750Vrms
Common Mode Transient Immunity (Min)	35kV/µs
Data Rate	150Mbps
Propagation Delay tpLH / tpHL (Max)	13ns, 13ns
Pulse Width Distortion (Max)	4.5ns
Rise / Fall Time (Typ)	2.5ns, 2.5ns
Voltage - Supply	2.5V ~ 5.5V
Temperature Range - Operating	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package	16-SOIC
Base Product Number	SI8631
Standard Package	2,500 pcs
Moisture Sensitivity Level (MSL)	2 (1 Year)
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	814486-SI8631EC-B-IS1R
Ultra Librarian 3D Model	Ultra Librarian SI8631EC-B-IS1R CAD Model

Alternative Products

Description

The SI8631EC-B-IS1R is a digital isolator designed for general-purpose applications.

Technology: Capacitive coupling
Data Rate: 150Mbps
Supply Voltage: 2.5V to 5.5V
Channels: 3
Voltage Isolation: 3750Vrms
Rise/Fall Time: 2.5ns
Propagation Delay: 13ns
Packaging: Tape and reel
Standard Package: 2,500 pieces
ECCN: EAR99
HTSUS Code: 8542.39.0001
Status: Active
MSL Level: 2
