SI8641BD-B-IS Real Image SI8641BD-B-IS Real Image
Same model may have multiple batches, images only for reference.
SI8641BD-B-IS Real Image SI8641BD-B-IS Real Image
SI8641BD-B-IS Real Image SI8641BD-B-IS Real Image
Same model may have multiple batches, images only for reference.

SI8641BD-B-IS

Part No SI8641BD-B-IS
Manufacturer Silicon Labs
Catalog Digital Isolators
Description DGTL ISO 5KV 4CH GEN PURP 16SOIC
Datasheet
SI8641BD-B-IS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Silicon Labs
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 3/1
Channel Type Unidirectional
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 35kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Pulse Width Distortion (Max) 4.5ns
Rise and Fall Time 2.5ns, 2.5ns
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 139447-SI8641BD-B-IS
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SI8641BD-B-IS CAD Model

Description

The Silicon Labs SI8641BD-B-IS is a general-purpose capacitive coupling technology isolator with four channels. Silicon Labs

  • Data Rate: 150Mbps
  • Channel Type: Unidirectional
  • Common Mode Transient Immunity: 35kV/μs
  • Propagation Delay: 13ns for both tpLH and tpHL
  • Pulse Width Distortion: 4.5ns
  • Rise and Fall Time: 2.5ns
  • Isolation Voltage: 5000Vrms
  • Case/Package: 16-SOIC
  • Operating Temperature Range: -40°C to 125°C
  • Supply Voltage Range: 2.5V to 5.5V
  • Status: Active
  • Popularity: Medium
