SI8640BD-B-ISR Real Image SI8640BD-B-ISR real image11047 SI8640BD-B-ISR Real Image1 SI8640BD-B-ISR Real Image2
Same model may have multiple batches, images only for reference.
SI8640BD-B-ISR Real Image SI8640BD-B-ISR real image11047 SI8640BD-B-ISR Real Image1 SI8640BD-B-ISR Real Image2
SI8640BD-B-ISR Real Image SI8640BD-B-ISR real image11047 SI8640BD-B-ISR Real Image1 SI8640BD-B-ISR Real Image2
Same model may have multiple batches, images only for reference.

SI8640BD-B-ISR

Part No SI8640BD-B-ISR
Manufacturer Silicon Labs
Catalog Digital Isolators
Description DGTL ISO 5KV 4CH GEN PURP 16SOIC
Datasheet
SI8640BD-B-ISR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Silicon Labs
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 35kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Pulse Width Distortion (Max) 4.5ns
Rise and Fall Time 2.5ns, 2.5ns
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 1096307-SI8640BD-B-ISR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SI8640BD-B-ISR CAD Model

Description

The SI8640BD-B-ISR is a 4-channel unidirectional general-purpose isolator from Silicon Labs.

  • Data rate: 150Mbps
  • Common mode transient immunity: 35kV/μs
  • Maximum propagation delay: 13ns for both tpLH and tpHL
  • Isolation voltage: 5000Vrms
  • Pulse width distortion: 4.5ns
  • Device operates in a temperature range of -40°C to 125°C
  • Available in a 16-SOIC package
  • Rise and fall time of 2.5ns
  • Suitable for use in isolator applications
