Same model may have multiple batches, images only for reference.
SI1002-CSB2-GM Real Image
Same model may have multiple batches, images only for reference.

SI1002-CSB2-GM

Part No SI1002-CSB2-GM
Manufacturer Silicon Labs
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU ISM<1GHZ 42WFQFN  /  IC RF TxRx + MCU General ISM < 1GHz EZRadioPro 240MHz ~ 960MHz 42-WFQFN Exposed Pad
Datasheet
SI1002-CSB2-GM Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category RF/IF and RFID>RF Transceiver ICs
Mfr Silicon Labs
Package Tube
Product Status Obsolete
Type TxRx + MCU
RF Family/Standard General ISM < 1GHz
Protocol EZRadioPro
Modulation FSK, GFSK, OOK
Frequency 240MHz ~ 960MHz
Data Rate (Max) 256kbps
Power - Output 13dBm
Sensitivity -121dBm
Memory Size 64kB Flash, 4.35kB RAM
Serial Interfaces I2C, SPI, UART
GPIO 22
Voltage - Supply 1.8V ~ 3.6V
Current - Receiving 18.5mA
Current - Transmitting 17mA ~ 30mA
Temperature Range - Operating -40°C ~ 85°C
Mounting SMD (SMT)
Package / Case 42-WFQFN Exposed Pad
Supplier Device Package 42-QFN (5x7)
Base Product Number SI1002
Standard Package 43
MSL Level 3 (168 Hours)
ECCN 5A991G
HTSUS 8542.31.0001
Win Source Part Number 1235754-SI1002-CSB2-GM
Ultra Librarian 3D Model Ultra Librarian SI1002-CSB2-GM CAD Model

Description

The SI1002-CSB2-GM from Silicon Labs is a versatile RF transceiver IC with a range of features.

  • Frequency: 240MHz to 960MHz
  • Data Rate: 256kbps
  • FLASH Memory: 64kB
  • RAM: 4.35kB
  • GPIO pins: 22
  • Package: 42-WFQFN exposed pad
  • Temperature: -40°C to 85°C
