SX1278IMLTRT Real Image1 SX1278IMLTRT Real Image2 SX1278IMLTRT real image
Same model may have multiple batches, images only for reference.
SX1278IMLTRT Real Image1 SX1278IMLTRT Real Image2 SX1278IMLTRT real image
SX1278IMLTRT Real Image1 SX1278IMLTRT Real Image2 SX1278IMLTRT real image
Same model may have multiple batches, images only for reference.

SX1278IMLTRT

Part No SX1278IMLTRT
Manufacturer Semtech Corporation
Catalog RF Transceiver ICs
Description RF ISM Transceiver FSK/GFSK/GMSK/MSK/OOK 3.3V 28-Pin QFN EP T/R / IC RF TXRX 802.15.4 28VQFN
Datasheet
SX1278IMLTRT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type TxRx Only
RF Family/Standard 802.15.4
Protocol LoRa
Modulation FSK, GFSK, GMSK, MSK, OOK
Frequency 137MHz to 525MHz
Data Rate (Max) 300kbps
Power - Output 20dBm
Sensitivity -148dBm
Serial Interfaces SPI
GPIO 6
Supply Voltage - Operating 1.8 V to 3.7 V
Current - Receiving 10.8mA to 12mA
Current - Transmitting 20mA to 120mA
Temperature Range - Operating -40°C to 85°C
Dimension 28-VQFN Exposed Pad
Win Source Part Number 105769-SX1278IMLTRT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Family Name SX1278
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SX1278IMLTRT CAD Model

Description

This Semtech Corporation SX1278IMLTRT component is a TxRx only type with a frequency range of 137MHz to 525MHz.

  • Protocol: LoRa
  • Sensitivity: -148dBm
  • Power Output: 20dBm
  • Data Rate: 300kbps (max)
  • Current (Receiving): 10.8mA to 12mA
  • Current (Transmitting): 20mA to 120mA
  • GPIOs: 6
  • Package: 28-VQFN Exposed Pad
  • Supply and Demand: Sufficient
  • Pieces per Package: 3k
