Same model may have multiple batches, images only for reference.

RCLAMP3654PATCT

Name: RCLAMP3654PATCT
Brand: Semtech Corporation
SKU: 291405
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	RCLAMP3654PATCT
Manufacturer	Semtech Corporation
Catalog	TVS - Diodes
Description	TVS DIODE 5.5VWM 30VC SLP1616P6
Datasheet	RCLAMP3654PATCT Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Semtech Corporation
Packaging	Reel - TR
Status	Active
Type	Steering (Rail to Rail)
Unidirectional Channels	3
STAND-OFF Voltage (Vwm)	5.5V (Max)
Minimum Breakdown Voltage	6.5V
Max Clamping Voltage	30V
Peak Pulse Current(Ippm)	3A (8/20μs)
Power Dissipation - Pd	100W
Power Line Protection	Yes
Applications	USB OTG
Capacitance @ Frequency	0.8pF @ 1MHz
Temperature Range - Operating	-55°C to 125°C (TJ)
Mounting	SMD (SMT)
Case / Package	SLP1616P6 (1.6x1.6)
Win Source Part Number	042305-RCLAMP3654PATCT
Family Name	RCLAMP3654P
Introduction Date	April 19, 2010
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2023
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian RCLAMP3654PATCT CAD Model

Description

The RCLAMP3654PATCT is a steering (rail to rail) Zener diode designed for USB OTG applications.

Stand-off Voltage: 5.5V
Minimum Breakdown Voltage: 6.5V
Package: SLP1616P6 (1.6x1.6) SMD (SMT)
Power Dissipation: 100W
Channels: 3 unidirectional
Capacitance: 0.8pF @ 1MHz
Protection: Power line protection
Ideal For: USB OTG circuit protection, such as mobile phones and tablets
Status: Active
Operating Temperature: -55°C to 125°C
