IT258 Real Image
Same model may have multiple batches, images only for reference.

IT258

Part No IT258
Manufacturer Schaffner EMC Inc.
Catalog Custom Parts (E - I)
Description Pulse Transformer 1: 1 0.62Ohm Prim. DCR 0.75Ohm Sec. DCR 80pF 4 Terminal PC Pin Thru-Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

DC Resistance (DCR) 620 mΩ
Depth 17.6 mm
Frequency 40 kHz
Height 11.3 mm
Height - Seated (Max) 11.3 mm
Inductance 2.5 mH
Isolation Voltage 3.2 kV
Lead/Base Style PC Pin
Length 17.6 mm
Max Operating Temperature 70 °C
Min Operating Temperature -25 °C
Mount PCB, Through Hole
Number of Pins 4
REACH SVHC No SVHC
Rise Time 250 ns
RoHS Compliant
Schedule B 8504500000, 8504500000
Weight 6.000006 g
Width 16.7 mm
Win Source Part Number 1206217-IT258
Categories Custom Parts
Manufacturer Schaffner EMC Inc.
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IT258 CAD Model

Description

The Schaffner EMC Inc. IT258 is a custom part with a length of 17.6mm, height of 11.3mm, and width of 16.7mm.

  • Length: 17.6mm
  • Height: 11.3mm
  • Width: 16.7mm
  • Inductance: 2.5mH
  • DC Resistance (DCR): 620 mΩ
  • Frequency: 40kHz
  • Rise Time: 250ns
  • Number of Pins: 4
  • Mounting: PCB, through hole
  • Isolation Voltage: 3.2kV
  • RoHS Compliant: Yes
  • Popularity: Medium
  • Supply and Demand Status: Limited
