The SSQ-112-03-G-S is a 2.54 mm pitch square post socket strip from Samtec, designed for board-to-board interconnect applications. This connector features a dual-row configuration with 12 positions per row, gold-plated contacts, and a single-ended design. The gold plating ensures optimal conductivity and corrosion resistance, crucial for reliable signal transmission.

Applications

• Board-to-board connections: For creating secure and efficient interconnections between PCBs.
• Data and telecommunications equipment: Employed in networking devices and communication systems.
• Industrial automation: Used in control systems and machinery requiring dependable connections.
• Medical equipment: Found in devices where signal integrity is critical.
• Testing and measurement devices: Suitable for equipment requiring precise and repeatable connections.

Features

• 2.54 mm pitch: Standard pitch allows for compatibility with a wide range of mating connectors and PCBs.
• Dual-row configuration: Increases connection density in a compact footprint.
• 12 positions per row: Provides a total of 24 contacts for signal and power transmission.
• Gold-plated contacts: Ensures excellent conductivity and resistance to corrosion.
• Single-ended design: Connects to one side of the PCB, simplifying assembly.
• High-temperature plastic insulator: Withstands reflow soldering processes.

Benefits

• Reliable connection: Gold-plated contacts ensure a stable and low-resistance connection, minimizing signal loss.
• Space-saving design: The compact form factor is ideal for applications where board space is limited.
• Durable construction: The robust materials and construction ensure a long lifespan.
• Versatile application: Suitable for various applications due to its standard pitch and reliable performance.
• Simplified assembly: Single-ended design makes it easy to integrate into existing systems.

Additional Details

The SSQ series from Samtec is widely recognized for its quality and versatility in board-to-board interconnect solutions. The insulator material is typically a high-temperature thermoplastic, making it suitable for reflow soldering processes. The current rating is generally around 3A per contact. This part is RoHS compliant, ensuring it meets environmental standards. When selecting a mating connector, consider using terminal strips or discrete wire connectors. Always refer to the manufacturer's datasheet for complete and accurate specifications to ensure compatibility with your application.
