SMM-109-01-S-S Real Image
Same model may have multiple batches, images only for reference.

SMM-109-01-S-S

Part No SMM-109-01-S-S
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Datasheet
SMM-109-01-S-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series Tiger Eye™ SMM
Package Tube
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board or Cable
Number of Positions 9
Number of Positions Loaded All
Pitch - Mating 0.079" (2.00mm)
Number of Rows 1
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Insulation Color Black
Insulation Height 0.140" (3.56mm)
Contact Length - Post 0.120" (3.05mm)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Current Rating (Amps) 3.2A per Contact
Voltage Rating 350VAC
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Contact Material Beryllium Copper
Base Product Number SMM-109
Other Names 2031-SMM-109-01-S-S,SMM-109-01-S-S
Standard Package 32
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1285340-SMM-109-01-S-S
Ultra Librarian 3D Model Ultra Librarian SMM-109-01-S-S CAD Model

Description

The SMM-109-01-S-S is a rectangular connector that comes in headers, receptacles, female sockets category.

  • Positions: 9
  • Connector Category: receptacle, female sockets
  • Connector Type: Receptacle Connector
  • Contact Type: female socket
  • Positions Loaded: All
  • Number of Rows: 1
  • Termination: solder
  • Fastening Type: push-pull
  • Package: tube
  • Contact Material: beryllium copper
  • Voltage Rating: 350VAC
  • Standard Package: 32 units
  • MSL Level: 1 (unlimited)
  • REACH Status: REACH unaffected
  • Manufacturer: Samtec Inc.
  • Also Known As: 2031-SMM-109-01-S-S, SMM-109-01-S-S
  • Base Product Number: SMM-109
