The SFMC-141-L1-F-D is a Tiger Eye™ SFMC series receptacle connector from Samtec Inc. with 82 positions.

• Positions: 82
• Style: Board-to-Board or Cable
• Pitch: 0.050" (1.27mm) for mating
• Insulation Material: Liquid Crystal Polymer (LCP)
• Insulation Color: Black
• Contact Material: Beryllium Copper
• Contact Finish: Gold (mating), Tin (post)
• Contact Finish Thickness: 3.00µin (0.076µm) for mating
• Mounting Type: Through-Hole
• Row Spacing: 0.050" (1.27mm) for mating
• Contact Length: 0.120" (3.05mm) for post
• Insulation Height: 0.180" (4.57mm)
• Contact Shape: Square
• Temperature Range: -55°C ~ 125°C
• Current Rating: 2.9A per contact
• Material Flammability: UL94 V-0
• Package: Tube
• Standard Package: 1
