The Samtec Inc. SFMC-120-01-S-D-K-TR is a Tiger Eye™ SFMC series connector that features 40 positions, pick and place, receptacle connector type, female socket contact type, all positions loaded, two rows, solder termination, push-pull fastening type, tape and reel package, beryllium copper contact material, and liquid crystal polymer insulation material.

• Series: Tiger Eye™ SFMC
• Positions: 40
• Pick and Place: Yes
• Connector Type: Receptacle
• Contact Type: Female Socket
• Positions Loaded: All
• Rows: Two
• Termination: Solder
• Fastening Type: Push-Pull
• Package: Tape and Reel
• Contact Material: Beryllium Copper
• Insulation Material: Liquid Crystal Polymer
• Voltage Rating: -
• Mated Stacking Heights: -
• Contact Finish-Mating: Gold
• Contact Finish Thickness-Mating: 30.0μin (0.76μm)
• Contact Finish-Post: Tin
• Insulation Color: Black
• Application: Board to Board or Cable
• Pitch-Mating: 0.050" (1.27mm)
