The Samtec Inc. SFC-125-T1-L-D-A is an electronic component with a Win Source Part Number of 1287851. It falls under the category of Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets. This component is a Tiger Eye™ SFC series with 50 positions and features a board guide. The connector type is a receptacle, and the contact type is a female socket. All positions are loaded, and it has two rows. The termination type is solder, and the fastening type is push-pull. The package is a tube, and the contact material is phosphor bronze. The voltage rating is 350VAC, and the insulation material is liquid crystal polymer (LCP). The pitch-mating is 0.050" (1.27mm), and the contact finish-mating is gold. The contact finish thickness-mating is 10.0µin (0.25µm), and the contact finish-post is tin. The insulation color is black, and the mounting type is through-hole. The row spacing-mating is 0.050" (1.27mm), and the contact length-post is 0.120" (3.05mm). The insulation height is 0.180" (4.57mm), and the contact shape is square. The temperature range for operating is -55°C ~ 125°C. The current rating (amps) is 3.1A per contact, and its REACH status is unaffected. The ECCN is EAR99, and the HTSUS is 8536.69.4040. Its manufacturer is Samtec Inc., and it has other names such as SAM11687 and SFC-125-T1-L-D-A.
