The SQW-113-01-F-D rectangular connector is a high-quality product from Samtec Inc.

• Series: SQW
• Positions: 26
• Connector Type: Receptacle
• Contact Type: Forked
• Positions Loaded: All
• Rows: 2
• Termination: Solder
• Fastening Type: Push-pull
• Contact Material: Phosphor bronze
• Voltage Rating: Not applicable
• Ingress Protection: Not applicable
• Material Flammability Rating: UL94 V-0
• Standard Package: 21
• Insulation Material: Liquid crystal polymer (LCP)
• Style: Board to board or cable
• Pitch of Mating: 0.079" (2.00mm)
• Contact Finish of Mating: Gold
• Contact Finish Thickness of Mating: 3.00µin (0.076µm)
• Contact Finish of the Post: Tin
• Insulation Color: Black
• Mounting Type: Through-hole
• Row Spacing of Mating: 0.079" (2.00mm)
• Contact Length of Post: 0.090" (2.29mm)
• Insulation Height: 0.250" (6.35mm)
• Contact Shape: Square
• Temperature Range of Operating: -55°C ~ 125°C
• MSL Level: 1 (Unlimited)
• Current Rating (amps): 3.8A per contact
• HTSUS: 8536.69.4040
• Base Product Number: SQW-113
