SQT-120-03-F-D Real Image
Same model may have multiple batches, images only for reference.

SQT-120-03-F-D

Part No SQT-120-03-F-D
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Datasheet
SQT-120-03-F-D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series SQT
Connector Type Receptacle
Contact Type Forked
Style Board to Board or Cable
Number of Positions 40
Number of Positions Loaded All
Pitch - Mating 0.079" (2.00mm)
Number of Rows 2
Row Spacing - Mating 0.079" (2.00mm)
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating Flash
Insulation Color Black
Insulation Height 0.250" (6.35mm)
Contact Length - Post 0.208" (5.28mm)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Current Rating (Amps) 5.1A per Contact
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Contact Material Phosphor Bronze
Base Product Number SQT-120
Other Names SQT-120-03-F-D,SAM11869
Standard Package 14
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1292351-SQT-120-03-F-D
Ultra Librarian 3D Model Ultra Librarian SQT-120-03-F-D CAD Model

Description

The SQT series is a board-to-board or cable receptacle connector from Samtec Inc.

  • Rows: Two
  • Positions Loaded: 40
  • Contact Type: Forked
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Insulation Color: Black
  • Contact Material: Phosphor Bronze
  • Contact Plating (Mating): Gold
  • Contact Plating (Post): Tin
  • Contact Finish Thickness: Flash
  • Contact Length (Post): 0.208 inches (5.28mm)
  • Contact Shape: Square
  • Pitch (Mating): 0.079 inches (2.00mm)
  • Mounting: Through-Hole
  • Row Spacing: 0.079 inches (2.00mm)
  • Insulation Height: 0.250 inches (6.35mm)
  • Operating Temperature: -55°C to 125°C
  • Current Rating: 5.1A per contact
  • ECCN: EAR99
  • HTSUS: 8536.69.4040
