ESQ-120-14-G-D

Name: ESQ-120-14-G-D
Brand: Samtec Inc.
SKU: 1293078
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	ESQ-120-14-G-D
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Datasheet	ESQ-120-14-G-D Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	ESQ
Package	Tube
Connector Type	Elevated Socket
Contact Type	Forked
Style	Board to Board
Number of Positions	40
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	20.0µin (0.51µm)
Insulation Color	Black
Insulation Height	0.435" (11.05mm)
Contact Length - Post	0.480" (12.19mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Gold
Current Rating (Amps)	5.7A per Contact
Voltage Rating	550VAC
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Contact Finish Thickness - Post	3.00µin (0.076µm)
Base Product Number	ESQ-120
Other Names	SAM8767,ESQ-120-14-G-D
Standard Package	11
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1293078-ESQ-120-14-G-D
Ultra Librarian 3D Model	Ultra Librarian ESQ-120-14-G-D CAD Model

Alternative Products

Description

The Samtec Inc. ESQ-120-14-G-D is a rectangular connector that has 40 positions and is suitable for board-to-board applications.

Insulation Material: Liquid Crystal Polymer (LCP)
Voltage Rating: 550VAC
Packaging: Tube
Contact Finish: Gold
