Same model may have multiple batches, images only for reference.

CLT-118-02-G-D-BE

Name: CLT-118-02-G-D-BE
Brand: Samtec Inc.
SKU: 1337222
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	CLT-118-02-G-D-BE
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN RCPT 36POS 0.079 GOLD SMD / 36 Position Receptacle, Bottom Entry Connector 0.079" (2.00mm) Surface Mount Gold
Datasheet	CLT-118-02-G-D-BE Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects - Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	CLT
Package	Tube
Connector Type	Receptacle, Bottom Entry
Contact Type	Female Socket
Style	Board to Board
Number of Positions	36
Number of Positions Loaded	All
Pitch - Mating	0.079" (2.00mm)
Number of Rows	2
Row Spacing - Mating	0.079" (2.00mm)
Mounting Type	Surface Mount
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	10.0µin (0.25µm)
Insulation Color	Black
Insulation Height	0.083" (2.10mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Gold
Current Rating (Amps)	4.1A per Contact
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Contact Finish Thickness - Post	3.00µin (0.076µm)
Base Product Number	CLT-118
Standard Package	16
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
California Prop 65	Warning Information
Win Source Part Number	1337222-CLT-118-02-G-D-BE
Ultra Librarian 3D Model	Ultra Librarian CLT-118-02-G-D-BE CAD Model

Alternative Products

Description

The CLT-118-02-G-D-BE is a rectangular connector used in electronic components. It has 36 positions and is a receptacle, bottom entry connector type.

Contact Type: Female Socket
Positions Loaded: All
Number of Rows: 2
Termination: Solder
Pitch-Mating: 0.079" (2.00mm)
Mated Stacking Height: -
Operating Temperature: -55°C to 125°C
ESD Protection: Yes
Lifecycle Status: Obsolete
