Same model may have multiple batches, images only for reference.
SI-B8R14156SWW Real Image
Same model may have multiple batches, images only for reference.

SI-B8R14156SWW

Part No SI-B8R14156SWW
Manufacturer Samsung
Catalog LED Lighting - COBs, Engines, Modules
Description LED SLIM 5000K 2290LM FRONT WIRE / LED Lighting COBs Engines Modules LED Module series White, Cool Linear Light Strip
Datasheet
SI-B8R14156SWW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics>LED Lighting - COBs, Engines, Modules, Strips
Mfr Samsung Semiconductor, Inc.
Series LT-S562F
Package Tray
Product Status Not For New Designs
Type LED Module
Color White, Cool
CCT (K) 5000K 3-Step MacAdam Ellipse
Configuration Linear Light Strip
Luminous Flux @ Current/Temperature 2290lm (Typ)
Current - Test 800mA
Temperature - Test 50°C
Voltage - Forward (Vf) (Typ) 17.6V
Lumens/Watt @ Current - Test 163 lm/W
Current - Max 1.44A
CRI (Color Rendering Index) 80
Viewing Angle 115°
Features With Connector
Dimension 559.70mm L x 23.80mm W
Height 5.80mm
Lens Type Flat
Base Product Number SI-B8
Other Names SI-B8R14156SWW,1510-1369
Standard Package 224
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 1240395-SI-B8R14156SWW
Ultra Librarian 3D Model Ultra Librarian SI-B8R14156SWW CAD Model

Description

The SI-B8R14156SWW is an LED module manufactured by Samsung Semiconductor, Inc.

  • Series: LT-S562F
  • Application: Optoelectronics applications such as LED lighting - COBs, engines, modules, strips
  • Color: White, cool color
  • CCT: 5000K 3-Step MacAdam Ellipse
  • Viewing Angle: 115°
  • Voltage-Forward (Vf): 17.6V
  • Current-Max: 1.44A
  • Configuration: Linear light strip
  • Package: Tray
  • Standard Package: 224
  • Durability: Reliable and durable
  • Installation: Easy to install and use
  • Cost-Effective Solution: High performance and efficiency
  • Compact Size and Lightweight Design: Suitable for use in applications where space is limited
