RF2514 Real Image
Same model may have multiple batches, images only for reference.

RF2514

Part No RF2514
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF) - Adapters
Description VHF/UHF TRANSMITTER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer RF Micro Devices
Win Source Part Number 1242560-RF2514
Manufacturer Homepage www.rfmd.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2514 CAD Model

Description

The RF2514 is a high-power, high-efficiency power amplifier module designed for use in 2.4GHz ISM band applications. Manufactured by RF Micro Devices, this module has a limited supply and demand status.

  • Operating Voltage: 3.6V to 4.2V power supply
  • Output Power: nominal 27dBm
  • Power-Added Efficiency: Typical 39 percent
  • Gain: 32dB
  • Ideal for: wireless LANs, Bluetooth, ZigBee, and other wireless communication systems.
