ISL84052IAZ Real Image ISL84052IAZ Real Image
Same model may have multiple batches, images only for reference.
ISL84052IAZ Real Image ISL84052IAZ Real Image
ISL84052IAZ Real Image ISL84052IAZ Real Image
Same model may have multiple batches, images only for reference.

ISL84052IAZ

Part No ISL84052IAZ
Manufacturer Renesas Electronics America
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Low Voltage, Single and Dual Supply, 8 to 1 Multiplexer, Dual 4 to 1 Multiplexer and a Triple SPDT Analog Switch | IC MUX/DEMUX DUAL 4X1 16QSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Renesas Electronics America Inc.
Packaging Bulk
Switch Circuit SP4T
On-State Resistance (Maximum) 100Ohm
Channel-to-Channel Matching (ΔRon) 6Ohm (Maximum)
Supply Voltage , Single (V+) 2V ~ 12V
Supply Voltage , Dual (V±) ±2V ~ 6V
Switch Time (Ton, Toff) (Maximum) 50ns, 40ns
Charge Injection 2pC
Channel Capacitance (CS(off), CD(off)) 3pF, 12pF
Current - Leakage (IS(off)) (Maximum) 2pA
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 16-SSOP
Supplier Device Package 16-QSOP
Family Part Number ISL84052
Manufacturer Pack Quantity 98
MSL Level 2 (1 Year)
Win Source Part Number 1190288-ISL84052IAZ
Manufacturer Homepage www.intersil.com/cda/home
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISL84052IAZ CAD Model

Description

The Renesas Electronics America Inc. ISL84052IAZ is a SP4T switch circuit device with a charge injection of 2pC.

  • Channel-to-Channel Matching: 6Ohm
  • Channel Capacitance CS(off): 3pF
  • Channel Capacitance CD(off): 12pF
  • On-State Resistance: 100Ohm
  • Switch Time Ton: 50ns
  • Switch Time Toff: 40ns
  • Supply Voltage Range Single: 2V to 12V
  • Supply Voltage Range Dual: ±2V to 6V
  • Package: 16-QSOP
  • Temperature Range: -40°C to 85°C
  • Popularity: Medium
  • Supply and Demand: Limited
