PE42521C-Z Real Image PE42521C-Z Real Image
Same model may have multiple batches, images only for reference.
PE42521C-Z Real Image PE42521C-Z Real Image
PE42521C-Z Real Image PE42521C-Z Real Image
Same model may have multiple batches, images only for reference.

PE42521C-Z

Part No PE42521C-Z
Manufacturer pSemi
Catalog RF Switches
Description IC RF SWITCH SPDT 13GHZ 16QFN / RF Switch IC General Purpose SPDT 13 GHz 50Ohm 16-QFN (3x3)
Datasheet
PE42521C-Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF/IF and RFID>RF Switches
Mfr pSemi
Series UltraCMOS®, HaRP™
Package Tape & Reel
RF Type General Purpose
Topology Absorptive
Circuit SPDT
Frequency Range 9kHz ~ 13GHz
Isolation 17dB
Insertion Loss 1.85dB
Test Frequency 13GHz
IIP3 65dBm
Impedance 50Ohm
Voltage - Supply 2.3V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Package / Case 16-VFQFN Exposed Pad
Supplier Device Package 16-QFN (3x3)
Base Product Number PE42521
Other Names 1046-1088-6,1046-1088-2,PE42521MLBA-Z,1046-1088-1
Standard Package 3,000
MSL Level 3 (168 Hours)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1235877-PE42521C-Z
Ultra Librarian 3D Model Ultra Librarian PE42521C-Z CAD Model

Description

The PE42521C-Z is an RF switch from pSemi.

  • Series: UltraCMOS®, HaRP™
  • Package: Tape and reel
  • Circuit: SPDT
  • Topology: absorptive
  • Impedance: 50Ohm
  • Test Frequency: 13GHz
  • Frequency Range: 9kHz to 13GHz
  • Insertion Loss: 1.85dB
  • Isolation: 17dB
  • IIP3: 65dBm
  • Voltage Supply: 2.3V to 5.5V
  • Package: 16-VFQFN exposed pad
  • Supplier Device Package: 16-QFN (3x3)
  • Operating Temperature: -40°C to 85°C
  • Standard Package: 3000 switches
  • ECCN: EAR99
