LNK305DG-TL Real Image LNK305DG-TL real image1855
Same model may have multiple batches, images only for reference.
LNK305DG-TL Real Image LNK305DG-TL real image1855
LNK305DG-TL Real Image LNK305DG-TL real image1855
Same model may have multiple batches, images only for reference.

LNK305DG-TL

Part No LNK305DG-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OCP 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Active
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package SO-8C
Mounting Surface Mount
Win Source Part Number 87975-LNK305DG-TL
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LNK305DG-TL CAD Model

Description

The Power Integrations LNK305DG-TL is a surface mount non-isolated integrated circuit that is commonly used in power applications.

  • Voltage Breakdown: 700V
  • Duty Cycle: 69%
  • Topology: Buck, buck-boost, and flyback
  • Switching Frequency: 66kHz
  • Fault Protection Features: Current limiting, open loop, over temperature, short circuit
  • Package: SO-8C
  • Category: Integrated Circuits
  • Operating Temperature Range: -40°C to 150°C (TJ)
  • Alternative Parts: LNK305GN-TL, LNK305G, LNK305P
  • Supply and Demand Status: Balanced
