The TISP3082F3 is a Transient Overvoltage Suppressor (TVS) from Power Innovations Ltd, designed to protect sensitive electronic circuits from voltage transients caused by lightning, electrostatic discharge (ESD), and inductive switching. This device is specifically designed for telecom applications, offering robust protection for subscriber line interface circuits (SLICs) and other sensitive components connected to telephone lines.

Applications

• Telephone line protection
• Subscriber Line Interface Circuits (SLICs)
• Modems
• Fax machines
• Data communication equipment
• Central office equipment

Features

• Transient Overvoltage Suppression: Provides robust protection against voltage transients.
• Low Clamping Voltage: Limits the voltage across the protected circuit during a transient event.
• High Surge Current Capability: Can withstand high surge currents without damage.
• Bidirectional Protection: Provides protection against both positive and negative voltage transients.
• Low Capacitance: Minimizes signal distortion in high-frequency applications.
• RoHS Compliant: Meets environmental regulations regarding hazardous substances.

Benefits

• Protection of Sensitive Circuits: Prevents damage to electronic circuits caused by voltage transients.
• Improved System Reliability: Enhances the overall reliability of the electronic device.
• Reduced Downtime: Minimizes downtime caused by transient-induced failures.
• Compliance with Telecom Standards: Meets industry standards for telecom protection.
• Cost-Effective Protection: Provides a cost-effective solution for protecting sensitive circuits.

Additional Details

The TISP3082F3 typically has a peak pulse current rating of several amperes and a clamping voltage in the range of tens of volts. The operating temperature range is typically -40°C to +85°C. It is available in various surface mount packages. Detailed specifications, including surge current waveforms, clamping voltage characteristics, and package dimensions, can be found in the manufacturer's datasheet.
