LCD4/0-14BF-X Real Image
Same model may have multiple batches, images only for reference.

LCD4/0-14BF-X

Part No LCD4/0-14BF-X
Manufacturer Panduit Corp
Catalog Rectangular Connectors
Description CONN TERM RECT TONG 4/0 AWG #1/4 / Terminal Connector Rectangular Rectangular Tongue 4/0 AWG 1/4 Stud
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Terminals - Rectangular Connectors
Mfr Panduit Corp
Series Pan-Lug®
Package Bulk
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Tab Thickness 0.140" (3.56mm)
Width - Outer Edges 1.060" (26.92mm)
Mounting Type Free Hanging (In-Line), Right Angle
Termination Crimp, Barrel
Wire Gauge 4/0 AWG
Insulation Non-Insulated
Color Purple
Contact Finish Electro-Tin
Contact Material Copper
Diameter - Barrel ID 0.570" (14.48mm)
Diameter - Barrel OD 0.710" (18.03mm)
Diameter - Ring ID 0.270" (6.86mm)
Base Product Number LCD4
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Other Names 07498356882,298-22267,LCD4/0-14BF-X-ND
Standard Package 1
Win Source Part Number 1203281-LCD4/0-14BF-X
Ultra Librarian 3D Model Ultra Librarian LCD4/0-14BF-X CAD Model

Description

The Panduit Corp 1203281-LCD4/0-14BF-X is a non-insulated, rectangular tongue terminal with a wire gauge of 4/0 AWG.

  • Stud/Tab Size: 1/4 stud
  • Tab Thickness: 0.140" (3.56mm)
  • Mounting: Free hanging (in-line) and right angle
  • Ideal for: Use in various connector and terminal applications
