XN4504 Panasonic
Same model may have multiple batches, images only for reference.

XN4504

Part No XN4504
Manufacturer Panasonic
Catalog Rectangular - Board to Board Connectors
Description CONN HEADER .8MM 50POS SMD
Datasheet
XN4504 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Panasonic Electric Works
Packaging Reel - TR
Status Active
Connector Type Header, Outer Shroud Contacts
Number of Positions 50
Pitch 0.031" (0.80mm)
Number of Rows 2
Mounting SMD (SMT)
Features Board Guide
Contact Finish Gold
Mated Stacking Heights 4mm, 4.5mm, 7mm
Height Above Board 0.147" (3.72mm)
Win Source Part Number 416107-XN4504
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian XN4504 CAD Model

Description

The Panasonic Electric Works 416107-XN4504 is a 50-position header connector with outer shroud contacts.

  • Position: 50
  • Contacts: Outer Shroud
  • Mounting: Surface-Mounted on PCB
  • Pitch: 0.031 inches (0.80mm)
  • Features: Board Guide
  • Contact Finish: Gold
  • Height Above the Board: 0.147 inches (3.72mm)
  • Mated Stacking Heights: 4mm, 4.5mm, and 7mm
  • Commonly Used In: Various electronic devices
  • Availability: Currently available in the market
