Same model may have multiple batches, images only for reference.
ELL-6UH330M Real Image
Same model may have multiple batches, images only for reference.

ELL-6UH330M

Part No ELL-6UH330M
Manufacturer Panasonic
Catalog Fixed Inductors
Description FIXED IND 33UH 1.1A 130 MOHM SMD / 33 µH Shielded Wirewound Inductor 1.1 A 130mOhm Nonstandard
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Panasonic Electronic Components
Series H
Package Tape & Reel
Product Status Obsolete
Type Wirewound
Inductance 33 µH
Tolerance ±20%
Current Rating (Amps) 1.1 A
Shielding Shielded
DC Resistance (DCR) 130mOhm
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.252" L x 0.236" W (6.40mm x 6.00mm)
Height - Seated (Max) 0.197" (5.00mm)
Base Product Number ELL-6UH
Standard Package 1,000
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1352221-ELL-6UH330M
Ultra Librarian 3D Model Ultra Librarian ELL-6UH330M CAD Model

Description

The 1167506 is a fixed inductor that belongs to the H series. Panasonic Electronic Components manufactures the inductor.

  • Series: H
  • Type: Wirewound, Shielded
  • Package: Tape & Reel
  • Size/Dimension: 0.252" L x 0.236" W (6.40mm x 6.00mm)
  • Inductance: 33 µH
  • Height Seated (Max): 0.197" (5.00mm)
  • Standard Package: 1,000
  • Tolerance: ±20%
  • DC Resistance (DCR): 130mOhm
  • Current Rating (Amps): 1.1 A
  • Inductance Frequency - Test: 100 kHz
  • Status: Obsolete
