EEH-ZA1H101P Real Image EEH-ZA1H101P Real Image1 EEH-ZA1H101P Real Image2
Same model may have multiple batches, images only for reference.
EEH-ZA1H101P Real Image EEH-ZA1H101P Real Image1 EEH-ZA1H101P Real Image2
EEH-ZA1H101P Real Image EEH-ZA1H101P Real Image1 EEH-ZA1H101P Real Image2
Same model may have multiple batches, images only for reference.

EEH-ZA1H101P

Part No EEH-ZA1H101P
Manufacturer Panasonic
Catalog Aluminum - Polymer Capacitors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum - Polymer Capacitors
Mfr Panasonic Electronic Components
Series ZA
Package Tape & Reel
Type Hybrid
Capacitance 100 µF
Tolerance ±20%
Voltage - Rated 50 V
ESR (Equivalent Series Resistance) 28mOhm
Lifetime @ Temp. 10000 Hrs @ 105°C
Temperature Range - Operating -55°C ~ 105°C
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 300 mA @ 100 Hz
Ripple Current @ High Frequency 2 A @ 100 kHz
Dimension 0.394" Dia (10.00mm)
Height - Seated (Max) 0.413" (10.50mm)
Surface Mount Land Size 0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting SMD (SMT)
Package / Case Radial, Can - SMD
Base Product Number EEH-ZA
Other Names P15442TR,P15442CT,P15442DKR,EEHZA1H101P
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1308433-EEH-ZA1H101P
Ultra Librarian 3D Model Ultra Librarian EEH-ZA1H101P CAD Model

Description

The Panasonic Electronic Components EEH-ZA1H101P is a hybrid aluminum-polymer capacitor designed for automotive applications.

  • Capacitance: 100 µF
  • Voltage Rating: 50 V
  • Tolerance: ±20%
  • ESR: 28mOhm
  • Ripple Current: 300 mA @ 100 Hz, 2 A @ 100 kHz
  • Series: ZA
  • Package: Tape and Reel
  • Surface Mount Land Size: 0.406" L x 0.406" W (10.30mm x 10.30mm)
  • Height: 0.413" (10.50mm)
  • Lifetime: 10000 hours @ 105°C
  • AEC-Q200: Rated
  • ECCN: EAR99
  • REACH: Unaffected
  • Also Known As: P15442TR, P15442CT, P15442DKR, and EEHZA1H101P
