DB3X314F0L Real Image DB3X314F0L Real Image
Same model may have multiple batches, images only for reference.
DB3X314F0L Real Image DB3X314F0L Real Image
DB3X314F0L Real Image DB3X314F0L Real Image
Same model may have multiple batches, images only for reference.

DB3X314F0L

Part No DB3X314F0L
Manufacturer Panasonic
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 30V MINI3
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Panasonic Electronic Components
Packaging Reel
Diode Configuration 1 Pair Series Connection
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 30V
Current - Average Rectified (Io) (per Diode) 30mA (DC)
Voltage - Forward (Vf) (Maximum) at If 1V at 30mA
Reverse Recovery Time (trr) 1ns
Current - Reverse Leakage at Vr 300nA at 30V
Operating Temperature - Junction 125°C (Maximum)
Mounting Style SMD
Manufacturer Package TO-236-3, SC-59, SOT-23-3
Supplier Device Package Mini3-G3-B
Part Number Series DB3X314
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805811-DB3X314F0L
Ultra Librarian 3D Model Ultra Librarian DB3X314F0L CAD Model

Description

The Panasonic Electronic Components DB3X314F0L is a Schottky diode.

  • Reverse Recovery Time (trr): 1ns
  • Maximum Operating Temperature: 125°C
  • Voltage - DC Reverse (Vr) (Maximum): 30V
  • Current - Average Rectified (Io) (per diode): 30mA (DC)
  • Voltage - Forward (Vf) (Maximum) @ If: 1V @ 30mA
  • Current - Reverse Leakage @ Vr: 300nA @ 30V
  • Diode Configuration: 1 Pair Series Connection
  • Supplier Device Package: Mini3-G3-B
  • Supply and Demand Status: Balanced
  • Manufacturer Package: TO-236-3, SC-59, SOT-23-3
  • Manufacturer Pack Quantity: 3,000
  • MSL Level: 1 (Unlimited)
