AXK8L80125BG Real Image
Same model may have multiple batches, images only for reference.

AXK8L80125BG

Part No AXK8L80125BG
Manufacturer Panasonic
Catalog Circular Connectors - Housings
Description CONN HDR 80POS SMD GOLD  /  80 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Datasheet
AXK8L80125BG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Panasonic Electric Works
Series F4
Package Tape & Reel (TR)
Connector Type Header, Outer Shroud Contacts
Number of Positions 80
Pitch 0.016" (0.40mm)
Number of Rows 2
Mounting SMD (SMT)
Features Solder Retention
Contact Finish Gold
Mated Stacking Heights 0.9mm
Height Above Board 0.025" (0.63mm)
Base Product Number AXK8L80125
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 3,000
Win Source Part Number 1177860-AXK8L80125BG
Ultra Librarian 3D Model Ultra Librarian AXK8L80125BG CAD Model

Description

The AXK8L80125BG is a rectangular connector array manufactured by Panasonic Electric Works.

  • Positions: 80
  • Pitch: 0.016" (0.40mm)
  • Connector Type: Header with outer shroud contacts
  • Rows: Two
  • Contact Finish: Gold
  • Package: Tape & reel (TR)
  • Mated Stacking Height: 0.9mm
  • Height Above Board: 0.025" (0.63mm)
  • Popularity: High
  • Supply and Demand Status: Balanced
