AXK5F80347YG Real Image
Same model may have multiple batches, images only for reference.

AXK5F80347YG

Part No AXK5F80347YG
Manufacturer Panasonic
Catalog Circular Connectors - Housings
Description CONN SOCKET 80POS SMD GOLD / 80 Position Connector Socket, Outer Shroud Contacts Surface Mount Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Panasonic Electric Works
Series P5KF
Package Tape & Reel
Connector Type Socket, Outer Shroud Contacts
Number of Positions 80
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Contact Finish Gold
Mated Stacking Heights 1.5mm
Height Above Board 0.053" (1.35mm)
Base Product Number AXK5F80347
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names AXK5F80347YG-ND,255-3126-2,255-3126-1,255-3126-6
Standard Package 2,000
Win Source Part Number 967774-AXK5F80347YG
Ultra Librarian 3D Model Ultra Librarian AXK5F80347YG CAD Model

Description

The AXK5F80347YG is a rectangular connector from Panasonic Electric Works designed for edge type mezzanine (board to board) connections.

  • Type: edge type mezzanine (board to board)
  • Positions: 80
  • Pitch: 0.020" (0.50mm)
  • Package: tape & reel
  • Standard Package: 2,000
  • Height above Board: 0.053" (1.35mm)
  • Mated Stacking Height: 1.5mm
  • Contact Finish: gold
  • Mounting: SMD (SMT)
  • ECCN: not restricted
  • MSL Level: 1 (unlimited)
  • HTSUS: 8536.69.4040
  • Market: popular
  • Supply and Demand: balance
