AQY211EHA Real Image AQY211EHA Real Image
Same model may have multiple batches, images only for reference.
AQY211EHA Real Image AQY211EHA Real Image
AQY211EHA Real Image AQY211EHA Real Image
Same model may have multiple batches, images only for reference.

AQY211EHA

Part No AQY211EHA
Manufacturer Panasonic
Catalog Solid State Relays
Description SSR RELAY SPST-NO 1A 0-30V / Solid State SPST-NO (1 Form A) 4-SMD (0.300", 7.62mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQY
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.14VDC
Voltage - Load 0 V ~ 30 V
Load Current 1 A
On-State Resistance (Max) 500 mOhms
Termination Style Gull Wing
Package / Case 4-SMD (0.300", 7.62mm)
Supplier Device Package 4-SMD
Base Product Number AQY211
Standard Package 100 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564444-AQY211EHA
Ultra Librarian 3D Model Ultra Librarian AQY211EHA CAD Model

Description

The AQY211EHA is a solid-state relay from Panasonic's PhotoMOS AQY series.

  • Type: single-pole single-throw normally open (SPST-NO)
  • Output Type: AC and DC
  • Voltage Input: 1.14VDC
  • On-State Resistance: 500 mOhms
  • Load Current: 1A
  • Voltage Load: 0V to 30V
  • Termination Style: gull wing
  • Mounting: surface mountable
  • Package: tube (100 pieces)
  • Standard Package: 4-SMD
  • Applications: industrial control, telecommunications, and measurement equipment
