3SK223 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Resistors
Manufacturer Panasonic Electronic Components
Packaging Bulk
Status Active
Resistance (Ohms) 22k
Tolerance ±5%
Power (Watts) 3W
Composition Metal Oxide Film
Features Flame Proof, Safety
Temperature Coefficient ±300ppm/°C
Temperature Range - Operating -55°C to 235°C
Case / Package Axial
Number of Terminations 2
Win Source Part Number 20747-3SK223
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 3SK223 CAD Model

Description

Features and Benefits

  • Low power loss
  • High switching speeds
  • Durable and long-lasting

Applications and Projects

  • DC-DC converters
  • Battery management systems
  • Portable electronics

The 3SK223 is a versatile component known for its high switching efficiency and low power loss, making it suitable for energy-conscious applications.
