ON Semiconductor 2SA1707S-AN PNP Transistor

The ON Semiconductor 2SA1707S-AN is a high-quality PNP transistor designed for use in a variety of electronic applications. This semiconductor device is well-suited for switching and amplification purposes, offering reliable performance in a compact package. Its robust construction and adherence to industry standards make it a preferred choice for engineers and designers looking for a dependable component for their circuits.

Key Features:

• Type: PNP Bipolar Transistor
• Package: SOT-23, a small surface-mount package that is ideal for space-constrained applications.
• Collector-Emitter Voltage (Vceo): -50V, providing a good margin for handling voltage spikes and ensuring stable operation under various conditions.
• Collector Current (Ic): -150mA, suitable for moderate current applications and ensuring efficient power handling capability.
• Gain Bandwidth Product (fT): 120MHz, allowing for good frequency response in amplification applications.
• DC Current Gain (hFE): High hFE rating, ensuring effective current amplification in the circuit.
• Power Dissipation (Pd): 150mW, adequate for low to medium power requirements, keeping the device cool during operation.

Applications:

The 2SA1707S-AN PNP transistor is versatile and can be used in various applications, including but not limited to:

• Audio amplifiers and pre-amps
• Signal processing circuits
• Switching power supplies
• Driver circuits for motors and relays
• General-purpose switching and amplification tasks

Quality and Reliability:

ON Semiconductor is known for its commitment to quality, and the 2SA1707S-AN is no exception. Each transistor is manufactured to meet rigorous standards, ensuring consistent performance and reliability. This component is suitable for commercial-grade equipment and can operate effectively over a wide temperature range, making it a solid choice for both industrial and consumer applications.

Whether you are designing a new piece of equipment or repairing an existing device, the ON Semiconductor 2SA1707S-AN PNP transistor is an excellent component to consider for your electronic circuit needs.
