XF2J-0624-12A-R100 Real Image
Same model may have multiple batches, images only for reference.

XF2J-0624-12A-R100

Part No XF2J-0624-12A-R100
Manufacturer Omron
Catalog FFC, FPC (FlatFlexible) Connectors
Description FFC & FPC Connectors FPC Connector
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Copper
Contact Plating Gold
Current Rating 500 mA
Gender Receptacle
Housing Material Polyamide
Length 8 mm
Mount Surface Mount
Number of Contacts 6
Number of Rows 1
Orientation Vertical
Packaging Cut Tape
REACH SVHC Unknown
RoHS Compliant
Termination SMD/SMT
Win Source Part Number 1178569-XF2J-0624-12A-R100
Categories FFC,FPC(FlatFlexible)Connectors
Manufacturer Omron
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian XF2J-0624-12A-R100 CAD Model

Description

The Omron XF2J-0624-12A-R100 is a 6-contact, 1-row receptacle connector used in FFC/FPC (Flat Flexible) Connectors.

  • Number of Contacts: 6
  • Number of Rows: 1
  • Connector Type: Receptacle
  • Application: FFC/FPC (Flat Flexible) Connectors
  • Current Rating: 500 mA
  • Contact Material: Copper
  • Housing Material: Polyamide
  • Length: 8 mm
  • Mounting: Surface Mounted
  • Contact Plating: Gold
  • Packaging: Cut Tape
  • Alternative Part Number: XF2J062412AR100
  • REACH SVHC: Unknown
  • ROHS Compliant: Yes
  • Manufacturer: Omron
