Products specifications

Manufacturer NXP
Win Source Part Number 1236982-PESD1CAN-U
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PESD1CAN-U CAD Model

Description

Introducing the PESD1CAN-U from NXP Semiconductors

The PESD1CAN-U is a state-of-the-art ESD protection device from the renowned semiconductor manufacturer NXP, specifically designed to safeguard CAN bus communication interfaces against electrostatic discharge (ESD) and other transient voltage events. This compact and robust component is an essential addition to any design requiring reliable protection for CAN (Controller Area Network) transceivers, which are commonly used in automotive and industrial applications.

Constructed with NXP's cutting-edge technology, the PESD1CAN-U offers bidirectional ESD protection up to 24 kV, ensuring compliance with the IEC 61000-4-2 standard. Its low clamping voltage and low capacitance minimize signal integrity impact, making it an ideal choice for high-speed data lines where maintaining signal quality is paramount.

Key Features of the PESD1CAN-U

  • High ESD Protection: Withstands ESD discharges up to 24 kV, offering robust defense against common electrostatic events.
  • Bidirectional Transient Voltage Suppression: Protects both lines of the CAN bus interface, ensuring comprehensive coverage.
  • Low Capacitance: A capacitance of just 10 pF (typical) allows for minimal signal attenuation, preserving the integrity of high-speed signals.
  • Low Clamping Voltage: Provides enhanced protection for sensitive transceiver ICs by limiting the voltage during transient events.
  • Small SOT-23 Package: Its compact footprint enables easy integration into space-constrained designs without sacrificing performance.
  • Automotive Qualification: Qualified according to AEC-Q101 standards, making it suitable for use in harsh automotive environments.

Whether you're designing in-vehicle networks, industrial automation systems, or any other application that relies on CAN bus technology, the PESD1CAN-U offers the reliability and performance you need. Its ability to provide high-level ESD protection while maintaining signal clarity is a testament to NXP's commitment to quality and innovation in circuit protection.

Choose the PESD1CAN-U for your next project and ensure your CAN bus interface remains secure against the unpredictable nature of ESD and other transient voltages, maintaining the reliability and longevity of your electronic systems.
