The MPX2200GP is a state-of-the-art pressure sensor from NXP Semiconductors, designed for a wide range of applications requiring a high degree of accuracy and reliability. This device is part of NXP's MPX series of silicon piezoresistive pressure sensors that offer a high-quality, cost-effective solution for measuring absolute pressure.

Key Features

• Pressure Range: The MPX2200GP is capable of measuring absolute pressure in the range of 0 to 200 kPa.
• Sensitivity: It provides a very high sensitivity output of 40 mV/kPa at a 10Vdc supply voltage, ensuring precise readings.
• Temperature Compensated: This sensor includes temperature compensation over the range of 0°C to +85°C, which helps maintain accuracy in varying environmental conditions.
• Linearity: The MPX2200GP offers excellent linearity and hysteresis, making it a reliable choice for critical measurements.
• Versatility: Its small form factor and robust design make it suitable for use in medical devices, industrial controls, and other precision applications.

Electrical Specifications

The MPX2200GP operates on a supply voltage of 10Vdc and has a full-scale output voltage of 40mV. It has a maximum offset voltage of ±1.0 mV, which ensures minimal deviation from true pressure readings.

Quality and Durability

NXP's commitment to quality is evident in the MPX2200GP's construction, which features a durable, stress-resistant package designed to withstand harsh conditions. The sensor is also protected against electrostatic discharge (ESD) events, ensuring long-term stability and performance.

Applications

The MPX2200GP is versatile and can be integrated into a variety of systems, including:

• Automotive engine control systems
• Medical instrumentation
• Industrial pressure monitoring
• Altimeters and barometers
• Fluid level indicators

Conclusion

With its precise measurements, temperature compensation, and robust construction, the MPX2200GP from NXP is an excellent choice for engineers and designers looking for a reliable pressure sensor that can deliver consistent, accurate data across a broad range of applications.
