Product Overview: MC9S08GT32ACFDE

The MC9S08GT32ACFDE is a high-performance microcontroller designed by NXP, tailored for a wide range of applications requiring a robust and efficient 8-bit processing unit. This microcontroller is part of the MC9S08 series, which is renowned for its integration, versatility, and cost-effectiveness. The MC9S08GT32ACFDE is particularly well-suited for industrial control, automotive, consumer electronics, and smart sensors.

Key Features

• Core: The device features an S08 core, which operates at a maximum frequency of 40 MHz, providing a balanced combination of processing power and energy efficiency.
• Memory: It comes with 32KB of on-chip flash memory, ensuring ample space for complex application code, and 2KB of RAM for efficient data manipulation.
• Timers: Multiple flexible timers including an 8-channel, 16-bit timer/pulse-width modulator (TPM) for accurate event timing and pulse generation.
• Analog-to-Digital Converter: An integrated 10-bit ADC with multiple channels offers precision analog input measurement capabilities.
• Communication Interfaces: The MC9S08GT32ACFDE includes I2C, SPI, and SCI serial communication modules to interface with a variety of peripherals and other microcontrollers.
• Input/Output: Generous I/O options with up to 70 GPIOs, providing a high level of interface flexibility.
• Operating Voltage: It operates within a range of 2.7V to 5.5V, accommodating various power supply requirements.
• Temperature Range: The device can operate within an industrial temperature range of -40°C to +85°C, making it reliable under extreme conditions.
• Packaging: This microcontroller comes in an 80-QFP (Quad Flat Package), ensuring compactness and ease of PCB mounting.

Applications

The MC9S08GT32ACFDE microcontroller's versatility makes it an excellent choice for a multitude of applications. It is commonly used in automotive systems for sensor management and control, in consumer electronics for smart appliances, in industrial automation for process control, and in medical devices where precision and reliability are paramount.

Design Support

NXP provides comprehensive design support for the MC9S08GT32ACFDE, including development tools, software libraries, and reference designs. This ensures that engineers can streamline the development process and bring their products to market more quickly and efficiently.
