Product Overview: 74LVC125AD - NXP Semiconductors

The 74LVC125AD is a high-performance, quad buffer/line driver with 3-state outputs from NXP Semiconductors, designed to deliver both high-speed and low-voltage operation suitable for a variety of digital applications. This integrated circuit is part of the LVC family, which is known for its low-voltage capabilities and compatibility with TTL levels.

Key Features

• Logic Type: Quad Buffer, Line Driver with 3-state outputs
• Operating Voltage: 1.2V to 3.6V, which allows for use in low-voltage applications and is compatible with various logic level standards.
• High-Speed Performance: Capable of propagating delays as low as 3.7ns, making it ideal for high-speed signal processing.
• Power Dissipation: Low power consumption with a maximum ICC of 40 µA, minimizing power waste in the system.
• I/O Capability: Can drive up to 24 mA at the output, providing sufficient current for many interfacing requirements.
• ESD Protection: Features input and output protection against electrostatic discharge, ensuring robustness for industrial applications.
• Package: Available in a 14-pin SOIC package, which is suitable for surface mount technology and provides a compact footprint.
• 5V Tolerant Inputs: Inputs are 5V tolerant, which enables interfacing with 5V logic without the need for additional level shifters.

Applications

The 74LVC125AD is versatile and can be used in a wide range of applications including:

• Bus interface or signal buffering in microcontroller-based systems
• Memory interfacing in computers and servers
• Signal driving for data transmission across PCBs
• Level shifting in multi-voltage systems

Quality and Reliability

NXP Semiconductors is committed to providing quality products, and the 74LVC125AD is no exception. It is manufactured under strict quality control standards and is designed to meet the reliability demands of the most challenging applications.
