B29AB Nihon Kaiheiki Industry Co. Ltd.
Same model may have multiple batches, images only for reference.

B29AB

Part No B29AB
Manufacturer NKK Switches
Catalog Toggle Switches
Description SUBMINIATURE TOGGLE/PC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - Toggle Switches
Mfr NKK Switches
Series B
Package Bulk
Product Status Active
Mounting Type Through Hole
Circuit DPDT
Switch Function On-Off-Mom
Current Rating (Amps) 0.4VA (AC/DC)
Voltage Rating - AC 28 V
Voltage Rating - DC 28 V
Actuator Type Standard Round
Actuator Length 8.00mm
Illumination Non-Illuminated
Termination Style PC Pin
Bushing Thread Unthreaded
Features Epoxy Sealed Terminals
Temperature Range - Operating -30°C ~ 85°C
Actuator Material Brass, Nickel Plated
Electrical Life 50,000 Cycles
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 567924-B29AB
Ultra Librarian 3D Model Ultra Librarian B29AB CAD Model

Description

The NKK Switches 567924-B29AB is a toggle switch in the B series.

  • Circuit: DPDT
  • Switch Function: on-off-mom
  • Termination Style: PC pin
  • Sealed: Epoxy
  • Actuator Material: Brass and nickel plated
  • Voltage Rating (AC/DC): 28V
  • Actuator Type: Standard round
  • Actuator Length: 8.00mm
  • Electrical Life: 50,000 cycles
  • Illumination: Non-illuminated
  • Mounting: Through hole
  • Operating Temperature: -30°C to 85°C
  • Current Rating: 0.4VA (AC/DC)
  • MSL Level: 1
  • ECCN: EAR99
  • HTSUS Code: 8536.50.9065
