The UPT2G3R3MEDCZX is an aluminum electrolytic capacitor manufactured by Nichicon. It is designed for general-purpose applications requiring a compact size and a wide operating temperature range. Aluminum electrolytic capacitors are commonly used in power supplies, audio equipment, and other electronic circuits for filtering, smoothing, and energy storage.

Applications

• Power Supplies
• Audio Equipment
• Consumer Electronics
• Industrial Equipment
• LED Lighting
• DC-DC Converters

Features

• Aluminum Electrolytic Capacitor
• Compact Size
• Wide Operating Temperature Range
• Long Life
• High Ripple Current Capability

Benefits

• Stable Performance Over Temperature
• High Reliability
• Compact Design
• Long Service Life
• Cost-Effective Solution

Additional Details

The UPT2G3R3MEDCZX has a capacitance of 3.3µF and a voltage rating of 400V. It belongs to the UPT series of capacitors from Nichicon. The capacitor offers stable performance over a wide operating temperature range, typically from -40°C to +105°C. Its compact size makes it suitable for space-constrained applications. The UPT2G3R3MEDCZX is designed for a long operational lifespan, contributing to the overall reliability of the electronic device in which it is used. It is commonly used for filtering and smoothing in power supplies and decoupling applications in digital circuits. The construction of the capacitor involves an etched aluminum foil anode and cathode separated by electrolyte-soaked paper. Specific electrical characteristics include ESR (equivalent series resistance), impedance, and ripple current rating, all important parameters for circuit design. It is RoHS compliant.
